11,00 €
Out of stock
| Technical specifications | Technical descriptions |
|---|---|
| Maximum sheet size: | Width- 1100 mm Length- 1600 mm |
| Minimum sheet size: | Width- 200 mm Length- 350 mm |
| Top sheet: | 130 – 450 gm/m2 |
| Bottom sheet: | from 250 gm/m2 thickness: 0,6 – 10 mm |
| Glue: | PVA type or as specified. |
| Feeder height: | Bottom: 800 mm Top: – mm |
| Registration accuracy: * | < ± 0,5 mm |
| Operating speed: * | Up to 1500 sheets/hour |
| Total installed power: | 4.0 kW |
| Electrics: | 400 V, 3-Phase, PE, neutral, 50/60 Cycles |
| Air requirements: | 6 bar; 80 psi Approximately 500 L/min Oil– and waterfree air |
| * Depending on the properties of materials used and existing operating conditions. |
